VOLVO PREMIUM TECH TOOL PTT 1.12 VCADS PRO 2.40(SOFT)

Place of Origin:

Guangdong, China (Mainland)


	Add to My Favorites
HiSupplier Escrow	Share \|

Product Detail

Delivery Date: 3-7days after order

PTT is a Windows-based diagnostic application specially designed to test, calibrate and program engine parameters.

Volvo Premium Tech Tool PTT 1.12 VCADS Pro 2.40(SOFT)

Attention :This software is in Dell D630 HDD , so please make sure you have Dell D630 laptop before you make the order , that is very important , thanks .

PTT is a Windows-based diagnostic application specially designed to test, calibrate and program engine parameters. This software supports VN, VT, VHD, WG, WX and AC from model year '98 forward.

Volvo VCADS Pro 2.40.00 offers an excellent software tool to assist customers and bodybuilders in performing their own diagnostic work on Volvo engines.

Tests for fault tracing of Volvo D7C, D11F, D12B, D12C, D12D, D13F, D16D and D16F engines are incorporated into PTT.

Many funtions in today's modern vehicles are controlled by electronic control units(ECUs). ECUs control components such as the engine, instrumentation and certain vehicles funtions. PTT is a toolbox that bundles diagnostic (VCADS) and repair applications (Guided Diagnostics) together making it a one stop shop for the technicians. The main purpose of PTT is to support the diagnostic & repair process and to make it easier for technicians to work with the tools provided. PTT provides access to vehicle and parameter programming, service information and diagnostics

VCADS is a windows - Base software tool developed to test, calibrate and program parameters on Volvo ECUs.

VCADS provides tests and calibrations for VOLVO vehicles that are equipped with the Vehicle Electronics '98(VECTRO II) or Version 2 electronic control systtems. The application consists of a number of standrd graphical interfaces, such as graphs and continuous displays of parameters values. The operations are organized in the menu according to function groups. Some ECUs have changeable parameters that can be use to adjust or customize certain functions. Volvo ECUs often have two types of parameters: Customer parameters and Vehicle paameters.

Customers parameters can be programmed locally using VCADS.

Adjustments and improvements

- Support for new models: FL and FE

- The Option dialog in the Tool menu has been updated.

- Manually entered chassis series are validated on the local computer.

- Possibility to correct parameter values that are incorrect according to specifications. Parameters with values that are not valid are marked with red color. Previously, this situation caused an error that interfered with parameter programming.

- Help desk tool is updated. The actions 1 - Update phone book and 3 - Change connection type are found under 1 - Central Communications Settings.

- Campaigns which have been downloaded in intermediate storage mode but are not reported will, after 30 days, be reported as not performed for safety reasons.

- If the hardware part number in the control unit differs from the hardware part number stored in the central systems, VCADS Pro will automatically check if there is an appropriate conversion kit available. If this is the case, a dialog box appears asking the user to run the conversion kit.

- New procedure for downloading of new versions of VCADS Pro.

- If there is unused or unreported software stored in Intermediate Storage, the user will be notified and have the possibility to view more detailed information.

- Help text updated with instructions for parameter programming by templates, the new Option dialog and information about new functionality in intermediate storage.

- Campaign handling will from now be reported after programming is finished and not at the next authenticated connection to central systems.

- The operation conversion kit has been split into two operations: Conversion kit and Accessory kit.

- Oscilloscope related operations for special tool 88890040 have updated oscilloscope software.

-Support tool 9998555 and 88890020
